Module LCD graphique série 160x32

Modules d'affichage graphique LCD série 160 * 32

Display Format Picture Model No. Size
(inch)		 Outline Dimension
(mm)		 Viewing Area
(mm)		 Active Area
(mm)		 View Direction Interface IC Part No. Control-Board Brightness
(cd/m²)		 Recommended Touch Screen Temperature
(°C)		 O-Film
160*32
BGB16032-01
BGB16032-01 4.27 116.00 × 35.00 × 11.5 83.00 × 18.50 76.76 × 15.32 6H / 12H 6800 8-bit parallel or SPI AIP31020 or Eqv. -20~+70
160*32
BGB16032-02
BGB16032-02 3.79 116.00 × 44.00 × 9.50 99.00 × 24.00 94.36 × 18.56 6H / 12H SPI & Parallel SBN1661G -20~+70
160*32
BGB16032-06
BGB16032-06 3.6 122.00 × 44.00 × 13.30 99.00 × 24.00 89.55 × 18.19 6H / 12H SPI & Parallel AIP31108 or Eqv -20-+70
160*32
BGB16032-05
BGB16032-05 3.6 122.00 × 44.00 × 13.3 99.00 × 24.00 89.55 × 18.19 6H / 12H SPI & Parallel AIP31020 or Eqv -20-+70
160*32
BGB16032-03A
BGB16032-03A 3.6 116.00 × 44.00 × 13.25 99.00 × 24.00 89.55 × 18.19 6H / 12H SPI & Parallel AIP31020 or Eqv -20-+70
