Символьные ЖК Модули 20x4 - Blaze Display Technology Co., Ltd.

● Character LCD 20x2 (5 x 8 dots)
● FSTN-Gray / STN-Gray / STN-YG / STN-Blue
● +3.3V / +5.0V power supply
● Viewing Direction: 6H / 12H
● Interface: 6800 4/8-bit parallel, optional SPI / I2C (RW1063 IC)
● Backlight (Side LED): White / Green / Blue / Yellow-Green / RGB / Orange / Amber
● Temp: N.T / W.T / Super W.T
● Fonts: English-Japanese / English-European / English-Cyrillic (Russian)

Display Format	Model No.	Outline Dimension (mm)	Viewing Area (mm)	Active Area (mm)	Interface	IC Part No.
20×4	BCB2004-08	146× 62.5× 14.00	123 × 42.6	118.85 × 38.1	Parallel	ST7066U or Eqv.
20×4	BCB2004-05	118.00× 43.00× 13.10	77.00 × 25.20	70.36 × 20.44	Parallel	ST7066U or Eqv.
20×4	BCB2004-04	116.00× 46.00× 8.50	76.00 × 25.20	70.40 × 20.80	Parallel	ST7066U or Eqv.
20×4	BCB2004-02	93.00× 58.00× 12.50	73.00 × 39.00	68.70 × 31.12	Parallel	ST7066U or Eqv.
20×4	BCB2004-02	93.00× 58.00× 12.50	73.00 × 39.00	68.70 × 31.12	Parallel	ST7066U or Eqv.
20×4	BCB2004-01	70.00 × 46.70 × 11.50	60.00 × 22.00	55.12 × 17.56	Parallel	ST7066U or Eqv.
