Display Format	Picture	Model No.	Size (inch)	Outline Dimension (mm)	Viewing Area (mm)	Active Area (mm)	View Direction	Interface	IC Part No.	Control-Board	Brightness (cd/m²)	Recommended	Touch Screen	Temperature (°C)	O-Film
2.4''		BDT-T2440-04	2.4''	42.70 × 60.20 × 3.55	40.32 × 56.26	36.72 × 48.96	12H	16BIT MCU	ST7789V.				Optional
2.4''		BDT-T2440-03	2.4''	42.72 × 60.26 × 2.50	40.32 × 56.26	36.72 × 48.96	12H	16BIT MCU	ST7789V.				Optional
2.4''		BDT-T2440-02	2.4''	42.72 x 60.26 x 3.40	40.32 × 56.26	36.72 × 48.96	12H	16BIT MCU	ST7789V.				RTP
2.4''		BDT-T2440-01	2.4''	42.70 × 60.20 × 2.40	40.32 × 56.26	36.72 × 48.96	12H	16BIT MCU	ST7789V.				Optional
2.4''		BDT-T2437-02	2.4''	42.72 × 60.26 × 2.30	40.32 × 56.26	36.72 × 48.96	12H	16 bit parallel	ILI9341V.				Optional
2.4''		BDT-T2437-01	2.4''	42.72 × 60.26 × 2.35	40.32 × 56.26	36.72 × 48.96	12H	16 bit parallel	ST7789S-G4A.				Optional
2.4''		BDT-T2410-01	2.4''	42.72 × 60.26 × 2.30	40.32 × 56.26	36.72 × 48.96		SPI	HX83471.				Optional
