Display Format	Picture	Model No.	Size (inch)	Outline Dimension (mm)	Viewing Area (mm)	Active Area (mm)	View Direction	Interface	IC Part No.	Control-Board	Brightness (cd/m²)	Recommended	Touch Screen	Temperature (°C)	O-Film
3.5''		BDT-T3554-03	3.5''	76.90 × 63.90 × 4.20	74.10 × 61.90	70.08 × 52.56	6H	RGB	HX8238-D				Optional
3.5''		BDT-T3554-01	3.5''	76.90 × 63.90 × 4.65	74.10 × 61.90	70.08 × 52.56	6H	RGB	HX8238-D				Optional
3.5''		BDT-T3554-01	3.5''	76.90 × 63.90 × 3.10	74.10 × 61.90	70.08 × 52.56	12H	RGB	HX8238-D.				Optional
3.5''		BDT-T3539-01	3.5''	54.66 x 82.94 x 3.54	52.96 x 81.34	48.96 × 73.44	12H	Optional	16BIT MCU				RTP
3.5''		BDT-T3537-01	3.5''	54.66 x 82.94 x 3.54	52.96 x 81.34	48.96 × 73.44	12H	16BIT MCU					RTP
