Display Format	Picture	Model No.	Size (inch)	Outline Dimension (mm)	Viewing Area (mm)	Active Area (mm)	View Direction	Interface	IC Part No.	Control-Board	Brightness (cd/m²)	Recommended	Touch Screen	Temperature (°C)	O-Film
7.0"		BDT-T7050-02	7.0"	164.90 × 100.00 × 4.45	156.80 × 89.15	154.2144 × 85.92		RGB	ILI5120-9G & ILI6150C-9G				Optional
7.0"		BDT-T7050-01	7.0"	165.00 × 100.00 × 4.80	156.79 × 89.20	154.08 × 85.92		RGB	ILI6122 & ILI5960				Optional
7.0"		BDT-T7040-04	7.0"	164.90 × 100.00 × 2.80	162.50 × 95.70	154.2144 × 85.92		RGB	ILI5120-9G & ILI6150C-9G				Optional
7.0"		BDT-T7040-03	7.0"	164.90 × 100.00 × 2.8	162.50 × 95.70	154.2144 × 85.92		RGB	ILI5120-9G & ILI6150C-9G				Optional
7.0"		BDT-T7040-02	7.0"	164.90 × 100.00 × 4.72	162.50 × 95.70	154.08 × 85.92		RGB	ST5623-G3-1 & ST5091-G3-1				Optional
7.0"		BDT-T7040-01	7.0"	164.90 × 100.00 × 3.52	162.50 × 95.70	154.08 × 85.92		RGB	ST5623-G3-1 & ST5091-G3-1				Optional
