Pantalla Grafica LCD BGB128128-01
Modelo No. BGB128128-01
Outline size（mm）： 92.00 × 106.00 × 12.10
Viewing Area：73.00 × 73.00
Active Area： 70.35 × 70.35
Controller IC： SAP1024 or Eqv.
Interface： 8080 Parallel
Remarks： 1×20PIN
Backlight：LED
<!--[if !supportLineBreakNewLine]-->
<!--[endif]-->
Part Number: BGB128128-01
● Graphic LCD 128 x 128 (dots)
● FSTN-Gray / STN-Gray / STN-YG / STN-Blue
● Built-in controller ((SAP1024 or Equivalent)
● +3.3V / +5.0V power supply
● 1/128 duty, 1/12bias
● Viewing Direction: 6H / 12H
● Interface: 8080 8-bit parallel
● Backlight (Side LED): White / Green / Blue / Yellow-Green / RGB / Orange / Amber
● Temp: N.T / W.T / Super W.T
