Pantalla Grafica LCD BGB12864-12
Modelo No. BGB12864-12
Outline size（mm）： 103.80 × 52.00 × 9.30
Viewing Area：72.50 × 39.50
Active Area： 66.52 × 33.24
Controller IC： AIP31108 or Eqv.
Interface： SPI & Parallel
Remarks： 2×10PIN
Backlight：LED
<!--[if !supportLineBreakNewLine]-->
<!--[endif]-->
Part Number: BGB12864-12
● Grahpic LCD 128 x 64 (dots)
● FSTN-Gray / STN-Gray / STN-YG / STN-Blue
● Built-in controller (AIP31108 or Equivalent)
● +3.3V / +5.0V power supply
● 1/64 duty, 1/9bias
● Viewing Direction: 6H / 12H
● Interface: 6800 4/8-bit parallel
● Backlight (Side LED): White / Green / Blue / Yellow-Green / RGB / Orange / Amber
● Temp: N.T / W.T / Super W.T
