Pantalla Gráfica LCD BGB16032-02
Modelo No. BGB16032-02
Outline size（mm）： 116.00 × 44.00 × 9.50
Viewing Area：99.00 × 24.00
Active Area： 94.36 × 18.56
Controller IC： SBN1661G.
Interface： SPI & Parallel
Remarks： 1×20PIN
Backlight：LED
<!--[if !supportLineBreakNewLine]-->
<!--[endif]-->
Part Number: BGB16032-02
● Graphic LCD 160 x 32 (dots)
● FSTN-Gray / STN-Gray / STN-YG / STN-Blue
● Built-in controller (SBN1661G or Equivalent)
● +3.3V / +5.0V power supply
● 1/32 duty, 1/5bias
● Viewing Direction: 6H / 12H
● Interface: 6800 8-bit parallel
● Backlight (Side LED): White / Green / Blue / Yellow-Green / RGB / Orange / Amber
● Temp: N.T / W.T / Super W.T
