Pantalla Grafica LCD BGB19264-07
Modelo No. BGB19264-07
Outline size（mm）： 120.00 × 62.00 × 12.50
Viewing Area：104.00 × 39.00
Active Area： 97.50 × 32.47
Controller IC： AIP31108 , AIP31107(OR-EQV).
Interface： SPI & Parallel
Remarks： 1×21PIN
Backlight：LED
Part Number: BGB19264-07
● Graphic LCD 192 x 64 (dots)
● FSTN-Gray / STN-Gray / STN-YG / STN-Blue
● Built-in controller (AIP31108 or Equivalent)
● +3.3V / +5.0V power supply
● 1/64 duty, 1/9bias
● Viewing Direction: 6H / 12H
● Interface: 6800 8-bit parallel
● Backlight (Side LED): White / Green / Blue / Yellow-Green / RGB / Orange / Amber
● Temp: N.T / W.T / Super W.T
